Description

The stylish, horizontal H-Series Windlasses use the reliable worm gearbox technology. The integral contactor simplifies wiring and is protected by a durable maincase. The unit s waterproof seal requires minimum maintenance, and since you can install it in one piece, getting started is quick and easy.

Features

• Quick, easy, one-piece installation
• Robust horizontal worm motor-gearbox for reliable performance
• Integral contactor protected by maincase
• Sealed waterproof unit reuires minimum maintenance
• Aluminium and composite maincase for reduced weight
• Stainless Steel warping drum and unique Wear and Abrasion Reduction Pattern finish
• H3 s come with reed switch and magnet fitted as standard for chain counter applications
• For Boats up to 14m (48ft)
• Dimensions 212mm H x 365mm D x 361mm W

• Notes:

  Kits include: Built-in-dual-direction contactor, breaker and rocker switch

  Manual recovery kit (Part No 66840045)
  Availablr on the H2 H3 as an optional extra, it remains fitted to the unit for user convenience.

  Gypsy Number		Chain Description		Rope Description
  505		5 16 BB, 5 16 US G4 ISO, 8mm DIN 766, 8mm ISO 4565		14-16mm 3-strand and 8-plait (5 8 only)
