The new generation Freedom HF is equipped with quick-connect AC terminals and ignition lockout capability. The quick-connect AC terminals enable quick installation eliminating the need for strain relief clamps. The ignition lockout feature helps to minimize battery drain by disabling the inverter when the ignition is turned off.

The Freedom HF Inverter Charger is one of the smallest, lightest, and most affordable inverter chargers in the market today. The Freedom HF Inverter Charger features modified sine wave output and is designed to operate entertainment systems and small appliances in boats, RV?s and trucks. The Freedom HF is available in three models: 1000 watts with a 20-amp charger, 1000 watts with a 55-amp charger and 1800 watts with a 40-amp charger.

Some of the key feature enhancements include quick-connect AC terminal block on both AC input and output for incredibly easy installation. The ignition lockout feature minimizes battery drain by disabling the inverter when the ignition is turned off.

Product Features

• Designed to power demanding loads such as microwave ovens, TVs, DVD players, small appliances and other electronic equipment
• Removable digital display pre-attached with 25? extension cable for remote system monitoring
• Ignition lockout feature helps to minimize battery drain
• Automatic three-stage battery charger
• Designed to be hardwired using quick-connect AC terminal blocks or by connecting AC through GFCI receptacles (included)
• Built-in 30-amp relay to automatically transfer between inverter power and incoming AC utility power
• Protection Features
  • Battery over-voltage and under-voltage protection
  • Over-temperature shutdown
  • Automatic overload protection
  • Short-circuit protection
  • Ground-fault protection
  • ETL certified to UL458 for use in mobile RV and commercial applications

  • Models		HF 1000		HF 1055		HF 1800
    Output Power		1000w		1000w		1800w
    Surge Power		2000w		2000w		3600w
    Output Frequency regulation		60 hz		60 Hz		60Hz
    Inverter Voltage Regulation		115 + – 10 Vrms		115 + – 10 Vrms		115 + – 10 Vrms
    Output Wave Form		Modified Sine Wave		Modified Sine Wave		Modified Sine Wave
    Efficiency ( Full Load)		> 80%		> 80%		> 80%
    Peak Efficiency		> 87%		> 87%		> 87%
    No-load input power (producing output voltage)		< 10 W		< 10 W		< 10 W
    Off mode current draw (Display Off )		< 1 mA		< 1 mA		< 1 mA
    Electrical Specifications
    Charge Rate		20A		55A		40A
    AC Input Voltage Range		90-130Vac		90-130Vac		90-130Vac
    AC Transfer Relay		30A		30A		30A
    Battery Voltage ( Nominal)		12vdc		12vdc		12vdc
    Operating Voltage Range		10.5-15.5Vdc		10.5-15.5Vdc		10.5-15.5Vdc
    Low battery Cut-out (Low Limit High Limit)		10.5Vdc 11.8Vdc		10.5Vdc 11.8Vdc		10.5Vdc 11.8Vdc
    AC Input ( Max Charge)		5Aac		10Aac		7.5Aac
    Default Bulk Charge Voltage Setting		14.2Vdc		14.2Vdc		14.2Vdc
    Default Float Charge Voltage Setting		13.5Vdc		13.5Vdc		13.5Vdc
    Battery Charge Outputs		One		One		One
    Charge Control		Three-stage		Three-stage		Three-stage
    Battery Type Settings		Flooded Gel AGM Fixed 13.5Vdc		Flooded Gel AGM Fixed 13.5Vdc		Flooded Gel AGM Fixed 13.5Vdc
    Equalization		No		No		No
    Internal Temperature-sensitive Charging		Yes		Yes		Yes
    General Specifications
    Optimal Operating Temperature Range		32° – 104° F		32° – 104° F		32° – 104° F
    Optional Remotes		Detachable Display		Detachable Display		Detachable Display
    Unit Weight		10lb		10lb		12.8lb
    Unit Dimensions		4.2 x 9.5 xx 15.5		4.2 x 9.5 xx 15.5		4.2×9.5×18.0
    Part Number		806-1020		806-1055		806-1840
